Dovre Isle Royale & Cape Cod Side Ceramic Glass Panel | 9 1/16" x 11 15/16"

Dovre Isle Royale & Cape Cod Side Ceramic Glass Panel – 9 1/16" x 11 15/16" (Part 434-5230)

Restore safe operation and clear firebox visibility with this OEM replacement ceramic glass side panel for Dovre Isle Royale and Dovre Cape Cod wood stoves. Precision-cut from high-temperature ceramic / pyro-ceramic glass, this transparent panel is interchangeable between the left and right sides and engineered to withstand extreme stove heat while maintaining excellent clarity.

Key Features:

• High-temperature ceramic / pyro-ceramic glass rated up to 1,400°F for continuous stove use
• Fully transparent panel restores sharp, unobstructed fire viewing
• Interchangeable design fits either right or left side positions
• Precision-cut OEM dimensions for proper fit and safe operation
• Proudly made in the USA using premium heat-resistant materials

Specifications:

• OEM Part Number: 434-5230
• Glass Type: Ceramic / Pyro-ceramic (not tempered)
• Dimensions: 9 1/16" wide x 11 15/16" high
• Shape: Half arch
• Compatibility: Dovre Isle Royale and Dovre Cape Cod wood stoves
• Panel Placement: Right or left side (interchangeable)
• Temperature Rating: Up to 1,400°F (760°C)
• Quantity: Sold individually (one panel)
• Gasket: Tape gasket sold separately

Installation Notes:

Allow the stove to cool completely before servicing. Remove the side panel retainers and carefully take out the damaged glass and old gasket material. Clean the glass channel thoroughly. Install new tape gasket around the perimeter of the replacement glass, position the panel evenly into the frame, and reinstall retainers snugly without overtightening to allow for proper thermal expansion.

Important:
This listing is for one glass panel only. If replacing both side panels, please order two. This is not tempered glass. Tempered glass cannot withstand the sustained high temperatures of wood stove operation and may fail above 450°F. Ceramic, pyro-ceramic, and neo-ceramic glass are engineered for continuous exposure up to 1,400°F, ensuring safe and reliable performance.

Why Choose Our Ceramic Stove Glass?

This USA-made replacement panel is precision-cut to OEM specifications for proper fit, long service life, and dependable heat resistance. It restores safety, efficiency, and crystal-clear fire viewing to your Dovre Isle Royale or Cape Cod stove.

Measurements: 9 1/16" x 11 15/16"
Glass Type: Ceramic 3/16 (5mm) Thickness (Pyroceram/Robax)
Operating temperature: Up to 760° C / 1,400° F
Color: Clear (ceramic glass has a transparent amber tint)
Part #: 434-5230
