Temperature Limit Controller | SPDT, Automatic Reset, 120°F–140°F Open/Close on Rise

Temperature Limit Controller – SPDT, Automatic Reset, 120°F–140°F Open/Close on Rise

Protect your heating or cooling system with this surface-mount Temperature Limit Controller. Featuring SPDT contacts and automatic reset, it opens or closes the circuit when temperatures reach 120°F–140°F, ensuring reliable system protection and fan bypass control.

Key Features:

• SPDT Contact Form – Supports both normally open and normally closed configurations
• Automatic Reset – Resets automatically once temperature drops back within safe limits
• High Load Capacity – Handles up to 25A resistive at 120V–240V AC
• Surface Mount Design – Easy installation on flat surfaces with two secure mounting points

Specifications:

• Switch Action: Open and Close on Temperature Rise
• Contact Form: SPDT (Single-Pole Double-Throw)
• Switch Closing Temp: 120°F–140°F
• Switch Opening Temp: 120°F–140°F
• Voltage Rating: 120V AC / 277V AC
• Resistive Amps: 25A @ 120V/240V AC, 21.6A @ 277V AC
• Inductive Amps: 10A @ 120V, 5A @ 240V
• Reset Type: Automatic
• Pilot Contact Rating: 125 VA
• Wire Connections: Spade Terminals (1/4")
• Mounting: Surface Mount with 2 Holes (1/8" dia, 1-5/8" CTC)
• Base Dimensions: 2" L x 1-5/8" W
• Overall Size: 1-1/2" H x 1-3/4" W x 1" D
• Weight: 0.9 oz
• Certifications: cULus Recognized
• Country of Origin: China
• Manufacturer Part Number: 6UED2
• Brand: Approved Vendor

Pairs well with: HVAC Parts

Enhance safety and performance in HVAC systems, heaters, or fan-controlled appliances with this dependable Temperature Limit Controller. With its automatic reset and high-current capacity, it's the ideal solution for temperature-sensitive applications.
