Archgard 32-Inch Pilot Tube, Nut and Sleeve Assembly

In stock
SKU: SO-FP0035
(0)
$27.88
Before You Order
Special Order Notice
This item is a Special Order product and requires additional processing before shipment. Please allow an additional 2–3 business days for order processing before shipping.
Pricing Notice
This product is priced at our lowest available rate and does not qualify for discount codes or promotional offers.
Questions before ordering? Call (877) 223-6999 — we’ll verify it with you.
SSL Secure Checkout

Need Assistance...

Email 217-223-0999

Archgard 32-Inch Pilot Tube, Nut and Sleeve Assembly

A 32-inch pilot-tube assembly supplied with nut and sleeve for matching Archgard and Brigantia applications. Match the original fittings and required tube length before ordering.

Key Features

  • 32-inch pilot-tube length
  • Includes nut and sleeve
  • Archgard references 301-6010 / 301-6016 / 301-6242
  • Tube assembly sold individually
  • Confirm fittings and appliance model revision

Specifications

Part reference: 301-6010 / 301-6016 / 301-6242. Sold individually.

Cross Reference

  • Archgard: 301-6010 / 301-6016 / 301-6242
  • Brigantia (Archgard): 301-6010 / 301-6016 / 301-6242

Fireplace Models

These model references help identify the original component. They do not guarantee fit for every production version. Confirm the exact original part number, configuration and appliance revision before ordering.

Archgard

  • 22-DVIE22LN-1 S/N 220124 AND UP
  • 22-DVIM22LN-1 S/N 230000 AND UP
  • 345-DVTE31LN-1 & 345-DVTE31LP-1 S/N 340106 AND UP
  • 345-DVTE31LN-1 & 345-DVTE31LP-1 S/N 340171 AND UP
  • 50-DVTE36CN-1 S/N 500000 AND UP

Product Description

One 32-inch pilot tube, nut and sleeve assembly. Pilot and gas valve are not included.

Important Note

Confirm availability and lead time before ordering. Gas and electrical fireplace components must be selected and installed by a qualified technician following the appliance instructions and applicable codes. Never bypass a safety device or assume compatibility from appearance alone.

Why Choose Total Hearth?

Clear specifications and part references help you select the correct replacement component.
