Lynn Manufacturing Replacement Quadrafire Baffle Board, 2700-I ACT, SRV7007-146, 2357A

2357A Quadra-Fire Baffle Board – Replaces SRV7007-146 – Fits 2700-I ACT Insert – Superwool Plus 2100°F – Made in USA

Restore efficient combustion and protect your insert’s internal components with the Lynn Manufacturing 2357A Replacement Baffle Board. Designed as a direct replacement for Quadra-Fire part SRV7007-146, this high-performance baffle board is engineered specifically for the Quadra-Fire 2700-I ACT wood-burning insert. Built from durable Superwool Plus, this advanced ceramic fiber alternative delivers exceptional heat resistance, long service life, and improved safety under extreme temperatures.

Key Features:
• Direct replacement for Quadra-Fire SRV7007-146
• Designed for Quadra-Fire 2700-I ACT inserts
• High-temperature rating up to 2100°F
• Superwool Plus construction – non-carcinogenic ceramic fiber alternative
• Rigidized gray finish for enhanced durability and structural integrity
• Helps maintain proper airflow and secondary combustion efficiency
• Made in the USA by Lynn Manufacturing

Specifications:
• Part Number: 2357A
• Replaces: SRV7007-146
• Product Type: Fiber Baffle Board
• Dimensions: Approx. 21" x 12" x 1/2"
• Material: Superwool Plus ceramic fiber alternative
• Color: Rigidized gray
• Temperature Rating: Up to 2100°F
• Manufacturer: Lynn Manufacturing
• Country of Origin: USA

Compatible Stove Brands & Models:
• Quadra-Fire 2700-I ACT wood insert

Fitment Note:
This replacement is designed for ACT (Advanced Combustion Technology) models using part number SRV7007-146. Always verify your existing part number and dimensions before ordering.

Important Note:
This product is made from Superwool Plus, a next-generation pyro-ceramic insulation material designed for high-temperature stove applications. It is not tempered glass. This material is engineered to withstand direct flame exposure and prolonged heat without cracking under thermal stress.

Pairs Well With:
Quadra-Fire insulation blankets (832-3390 / Lynn 2350E), firebrick panels, secondary air tubes, and combustion system components.

Why Choose the Lynn Manufacturing 2357A Baffle Board?
A cracked or deteriorated baffle can reduce heat output, increase emissions, and disrupt proper combustion. Replacing your baffle with the 2357A restores proper airflow, improves secondary burn efficiency, and helps maintain EPA-compliant performance while protecting internal components.

Installation Instructions:
Allow the insert to cool completely before servicing.
Remove access panels or components to reach the baffle area.
Carefully remove the existing baffle board.
Clean and inspect support ledges.
Install the new 2357A board in the correct orientation.
Ensure it sits flat and is fully supported.
Reassemble components and verify proper placement before operation.

Installation Tip:
Never operate your insert without a properly installed baffle board and insulation blanket. Doing so can reduce efficiency and damage internal components.

Restore efficiency, improve combustion, and extend the life of your insert with the Lynn Manufacturing 2357A Quadra-Fire Baffle Board—engineered for durability, safety, and reliable high-temperature performance.
