Adjustable Temperature Limit Controller | 6UEE1 | Close on Rise, SPST, 90°F–130°F Closing, 70°F–110°F Opening | Surface Mount Thermo-Disc

Adjustable Temperature Limit Controller (6UEE1) – Close on Rise, SPST, 90°F–130°F Closing, 70°F–110°F Opening – Surface Mount Thermo-Disc
Control your system’s operation with this low-range adjustable temperature limit controller. Featuring a close-on-rise design, this surface-mount SPST thermo-disc is ideal for activating circuits such as fans or blowers as the temperature increases. Perfect for HVAC units, pellet stoves, and other heat-activated systems requiring precise thermal control.

Key Features:

• Close on Rise – Closes circuit as the temperature increases for active component control
• Automatic Reset – Resets once temperature drops below the opening threshold
• Adjustable Temperature Range – Offers flexibility from 70°F to 130°F
• Surface Mount – Simple and secure two-hole flat-surface installation

Specifications:

• Switch Type: SPST (Single Pole Single Throw)
• Closing Temperature Range: 90°F – 130°F
• Opening Temperature Range: 70°F – 110°F
• Temperature Differential: 20°F
• Mounting Style: Surface mount with screw holes
• Reset Type: Automatic
• Model Number: 6UEE1

Pairs well with: HVAC Parts and Pellet Parts

Fitment Note:
Best used for temperature-activated systems such as blower fans, duct heaters, and HVAC circuits. Be sure to confirm mounting location is thermally suitable for optimal operation.

This adjustable thermal switch provides reliable low-temperature control with a compact, rugged design. Ideal for activating components based on heat rise, it’s a dependable choice for safety and automation.
